Nginx web page configuration tool
QQ Group1: 1106758598 QQ Group2: 560797506
official website: http://www.nginxwebui.cn
NginxWebuUI is a graphical management tool for nginx configuration. You can use web pages to quickly configure various functions of nginx, including HTTP forwarding, TCP forwarding, reverse proxy, load balancing, static HTML server, SSL certificate automatic application, renewal, configuration, etc. Nginx. conf file can be generated after configuration, and nginx can be controlled to use this file for startup and reload, complete the graphical control of nginx closed loop.
The nginx webui allows you to manage multiple Nginx server clusters. You can switch to the corresponding server for nginx configuration at any time. You can also synchronize the configuration of a server to other servers with one click, facilitating cluster management.
The nginx web user interface (webui) does not cover all nginx functions, but covers 90% of the daily nginx configuration. If nginx configuration items are not covered by the platform, you can use custom parameter templates to generate unique configuration parameters in the CONF file.
After the deployment of this project, the configuration of nginx no longer need to search the web configuration code, no longer need to manually apply for and configure SSL certificates, just need to add, delete, change and check in this project can easily configure and start nginx.
Video course: https://www.bilibili.com/video/BV18A4y1D7GZ Demo address: http://test.nginxwebui.cn:7070 User: admin password: admin
This project is a Web system based on solon. The database use h2, so there is no need to install any database on the server.
This system applies for the certificate through Let's ENCRYPT and USES acme.sh script to automatically apply for and renew the certificate. Once the certificate is renewed, it will be renewed at 2 am every day, and only certificates exceeding 60 days will be renewed.
When adding TCP/IP forwarding configuration support, some lower versions of Nginx may need to be recompiled,You can install the stream module by adding the -with-stream parameter, but under Ubuntu 18.04, the nginx in the official software library already has the stream module, which does not need to be recompiled. If the TCP forwarding item is configured in this system, the configuration item of ngx_stream_module.so will be introduced automatically, and the configuration file of Ngnix will be optimized to the maximum.
Take the Ubuntu operating system, for example.
Note: This project needs to run the system command under the root user, which is very easy to be exploited by hackers. Please be sure to change the password to complex password
1.Install the Java runtime environment and Nginx
apt install openjdk-11-jdk apt install nginx
yum install java-11-openjdk yum install nginx
Download the JDK installation package https://www.oracle.com/java/technologies/downloads/ Download the nginx http://nginx.org/en/download.html Configure the JAVA runtime environment JAVA_HOME : JDK installation directory Path : JDK installation directory\bin reboot
2.Download the latest release of the distribution jar
Linux: wget -O /home/nginxWebUI/nginxWebUI.jar http://file.nginxwebui.cn/nginxWebUI-3.3.0.jar Windows: Download directly from your browser http://file.nginxwebui.cn/nginxWebUI-3.3.0.jar
With a new version, you just need to change the version in the path
Linux: nohup java -jar -Dfile.encoding=UTF-8 /home/nginxWebUI/nginxWebUI.jar --server.port=8080 --project.home=/home/nginxWebUI/ > /dev/null & Windows: java -jar -Dfile.encoding=UTF-8 D:/home/nginxWebUI/nginxWebUI.jar --server.port=8080 --project.home=D:/home/nginxWebUI/
Parameter description (both non-required)
--server.port Occupied port, default starts at port 8080
--project.home Project profile directory for database files, certificate files, logs, etc. Default is /home/nginxwebui/
--spring.database.type=mysql Use other databases, not filled with native h2, options include mysql
--spring.datasource.url=jdbc:mysql://ip:port/nginxwebui Databases url
--spring.datasource.username=root Databases user
--spring.datasource.password=pass Databases password
Note that the Linux command ends with an & to indicate that the project is running in the background
Docker image supports x86_64/arm64/arm v7 platforms. Note that an & sign is added at the end of the command, indicating that the docker image of this project has been produced by the background operation of the project, including nginx and nginxWebUI, for integrated management and operation of Nginx.
1.Install the Docker environment
apt install docker.io
yum install docker
docker pull cym1102/nginxwebui:latest
docker run -itd -v /home/nginxWebUI:/home/nginxWebUI -e BOOT_OPTIONS="--server.port=8080" --privileged=true --net=host cym1102/nginxwebui:latest
When you start the container, use the --net=host parameter to map the native port directly, because internal Nginx may use any port, so you must map all the native ports.
Container need to map path/home/nginxWebUI:/home/nginxWebUI, this path for a project all data files, including database, nginx configuration files, log, certificate, etc., and updates the mirror, this directory to ensure that project data is not lost. Please note that backup.
-e BOOT_OPTIONS Parameter to populate the Java startup parameter, which can be used to modify the port number
--server.port Occupied port, do not fill the default port 8080 startup
moreover: The following configuration file is used when using docker-compose
version: "3.2" services: nginxWebUi-server: image: cym1102/nginxwebui:latest volumes: - type: bind source: "/home/nginxWebUI" target: "/home/nginxWebUI" environment: BOOT_OPTIONS: "--server.port=8080" privileged: true network_mode: "host"
Compile the package with Maven
mvn clean package
Compile the image with Docker
docker build -t nginxwebui:latest .
[Unit] Description=NginxWebUI After=syslog.target After=network.target [Service] Type=simple User=root Group=root WorkingDirectory=/home/nginxWebUI ExecStart=/usr/bin/java -jar /home/nginxWebUI/nginxWebUI.jar Restart=always [Install] WantedBy=multi-user.target
systemctl daemon-reload systemctl enable nginxwebui.service systemctl start nginxwebui.service
open http://xxx.xxx.xxx.xxx:8080 Enter the main page
The login page, opened for the first time, asks to initialize the administrator account
After entering the system, you can add and modify the administrator account in the administrator management
In the HTTP parameters can be configured in the configuration of nginx HTTP project forward HTTP, the default will give several commonly used configuration, other configuration are free to add and delete. You can check the open log to track and generate log.
Nginx's Stream project parameters can be configured in the TCP parameter configuration, but in most cases they are not.
In the reverse proxy, the reverse proxy of Nginx, namely the Server item function, can be configured to enable SSL function, can directly upload PEM file and key file from the web page, or use the certificate applied in the system, can directly enable HTTP switch HTTPS function, or can open http2 protocol
In load balancing, the upstream function of Nginx can be configured. In reverse agent management, the configured load balancing agent target can be selected
In the HTML static file upload can be directly uploaded HTML compression package to the specified path, after uploading can be directly used in the reverse proxy, save the steps of uploading HTML files in Linux
In the certificate management, you can add the certificate, issue and renew it. After the periodic renewal is started, the system will automatically renew the certificate which will expire soon. Note: the certificate is issued using the DNS mode of Acme. sh, and it needs to be used together with aliKey and aliSecret of Aliyun
Backup file management. Here you can see the backup history version of Nginx.cnF. If an error occurs in Nginx, you can choose to roll back to a certain history version
Finally, the conF file can be generated, which can be further modified manually. After the modification is confirmed to be correct, the native conF file can be overwritten, and the effectiveness and restart can be carried out. You can choose to generate a single Nginx.conf file or separate each configuration file under conF.d by domain name
Remote server management. If you have multiple Nginx servers, you can deploy nginxWebUI, log in to one of them, add the IP and username and password of other servers to the remote management, and then you can manage all Nginx servers on one machine.
Provides one-click synchronization to synchronize data configuration and certificate files from one server to another
This system provides the HTTP interface to invoke. Open the page http://xxx.xxx.xxx.xxx:8080/doc.html to view the smart-doc interface.
The interface invocation requires adding a token to the HTTP request header. To obtain the token, you need to enable the interface invocation permission of the user in the administrator management system, and then invoke the interface to obtain the token using the user name and password.
If you forget your login password or do not save the two steps verify, follow the instructions below to retrieve the password and turn off the two steps verify.
2.Run nginxWebUI.jar with the retrieve password parameter.
java -jar nginxWebUI.jar --project.home=/home/nginxWebUI/ --project.findPass=true
--project.home Project profile directory
--project.findPass Whether to print the user name and password
After the operation is successful, all user names and passwords can be printed and two steps verify is disabled.
